Buildings should respond intelligently to security events—not just sound an alarm.
When an intrusion is detected, lights should illuminate escape routes. When fire alarms trigger, blinds should open automatically. When you arm your system at night, the entire building should shift into security mode.
We believe professional alarm systems and building automation belong together. Security events shouldn't exist in isolation—they should orchestrate your entire KNX installation to protect people and property more effectively.
That's why we created the Elausys KNX Alarm Gateway range.
One Unified Approach
Multiple Alarm Brands
Elausys alarm gateways share a unified ETS application concept across all supported alarm families.
- Learn once, deploy everywhere — Same ETS configuration logic for Ajax, Jablotron, Paradox, Interlogix, GE Caddx, or AnB Rimex
- Reduced engineering time — Consistent parameter structures across all gateway models
- Predictable commissioning — Familiar workflows regardless of alarm brand
Bidirectional Real-Time Communication
True Integration, Not Just Monitoring
Every gateway provides true bidirectional integration between your alarm system and KNX installation.
- Monitor zone status, area states, and alarm events from KNX
- Control arming, partial arming, and disarming directly from KNX visualisation or push-buttons
- Link event outputs (PG/PGM) to KNX loads for automated responses
Core Capabilities
Capability
Specification
Zone Monitoring
Up to 96 zones with individual KNX group objects
Programmable Outputs
Up to 32 PG/PGM for flexible alarm-to-KNX linkage
Area Control
Up to 4 areas with arm, partial arm, disarm + status feedback
Area Status Feedback
Disarmed, entry delay, exit delay, armed, partial armed, fire alarm, siren on, panic, intrusion
Scene Integration
Automatic KNX scene recall on each area status change
Motion-Triggered Lighting
Use alarm motion detectors to control KNX lighting
Zone/Area Mapping
Flexible offset configuration for multi-gateway installations
Key Benefits for Integrators
Enhanced Building Intelligence
Transform passive alarm systems into active building automation triggers:
- -Intrusion detected — Emergency lighting activates, blinds open
- -Fire alarm — Escape route illumination, elevator recall, ventilation shutdown
- -System armed — Night scene activation, presence simulation, energy saving mode
- -Motion detected — Courtesy lighting in corridors, stairwells, or entry points
Simplified End-User Experience
Clients control their alarm system from the same KNX interface they use for lighting and blinds—no separate apps or keypads required for basic operations.
Gateway Models
Complete range of gateways for major alarm system brands
Alarm System
Gateway
Zones
PG Outputs
Areas Control
Ajax Alarm Systems
AJAX-KNX
96
-
Yes
Jablotron 100 series
JA-KNX
96
32
Yes
Interlogix UltraSync
NXG-KNX
96
—
Yes
GE Caddx NetworX
GE NETWORX KNX
96
—
Yes
Paradox EVO
Paradox KNX
96
32
Yes
AnB Rimex TRICOM
ANB-KNX
96
—
—
